FEATURES
- Equipped with imported power unit, reliable quality and superior performance
- Fitted with metal halide lamps featuring high luminous flux and long service life
- High-performance self-braking hand winch
- 3-section galvanized lifting mast, anti-fall and corrosion-resistant
- Five wind-resistant support legs for stable placement
- Integrated control panel with rain cover
- Maximum lifting height of 9 meters, adjustable lighting angle for long irradiation distance
- Large-capacity fuel tank for extended continuous operation
| Item | Unit | Value |
|---|---|---|
| Overall Length (L) | mm | 4400 |
| Overall Width (W) | mm | 1670 |
| Overall Height (H) | mm | 1830 |
| Extended Lifting Height (HI) | m | 9 |
| Tire & Rim Size (WI) | inch | 14 |
| Item | Unit | Changchai | YANMAR | Kubota |
|---|---|---|---|---|
| Engine Brand | — | Changchai | YANMAR | Kubota |
| Engine Model | — | 3M78/CZ380Q | 3TNV76 | D1105 |
| Engine Type | — | 3-cylinder, water-cooled, 4-stroke | 3-cylinder, water-cooled, 4-stroke | 3-cylinder, water-cooled, 4-stroke |
| Power Output | kw | 11.5/14.3 | 10.7 | 12.6 |
| Rated Speed | rpm | 1500 | 1500 | 1500 |
| Combustion System | — | E-TVS | E-TVS | E-TVS |
| Air Intake Type | — | Naturally Aspirated | Naturally Aspirated | Naturally Aspirated |
| Emission Standard | — | Conventional Standard | Conventional Standard | Conventional Standard |
| Standard Generator | — | SPARKS | SPARKS | SPARKS |
| Rated Voltage (50/60Hz) | V | 230/240-120 | 230/240-120 | 230/240-120 |
| Motor Insulation Class | — | CLASS H | CLASS H | CLASS H |
| Motor Protection Class | — | IP23 | IP23 | IP23 |
| Main Lamp Type | — | Metal Halide Lamp | — | LED Lamp |
| Lamp Quantity & Power | w | 1000×4 | — | 400×4 |
| Luminous Flux | lm | 440000 | — | 224000 |
| Mast Sections | Sections | 3 | 3 | 3 |
| Fuel Tank Capacity | L | 110 | 110 | 110 |
| Continuous Operation Time | h | 80 | 80 | 80 |
| Unit Starting Mode | — | Key Start | Key Start | Key Start |
| Max. Wind Resistance Speed | m/s | 20 | 20 | 20 |
| Noise Level | dB | 72 at 7 Meters | 72 at 7 Meters | 72 at 7 Meters |
| Suspension & Brake | — | Leaf Spring Suspension, Single Axle Without Brake | Leaf Spring Suspension, Single Axle Without Brake | Leaf Spring Suspension, Single Axle Without Brake |
| Drawbar | — | With Retractable Adjustable Guide Wheel Lever | With Retractable Adjustable Guide Wheel Lever | With Retractable Adjustable Guide Wheel Lever |
| Max. Lifting Height | m | 9 | 9 | 9 |
| Tire Size | inch | 14 | 14 | 14 |
| Maximum Towing Speed | km/h | 100 | 100 | 100 |
| Overall Length | mm | 4400 | 4400 | 4400 |
| Overall Width | mm | 1670 | 1670 | 1670 |
| Overall Height | mm | 1830 | 1830 | 1830 |
| Total Weight | kg | 980 | 980 | 980 |
Reliable Performance
Stable performance across all working conditions for efficient, consistent operation.
Durable Construction
Reinforced frame & premium parts extend service life.
Wide Product Selection
Full lineup: construction, landscaping, road compaction & mobile lighting gear for diverse industries.
Flexible Configuration
Customizable models, power, capacity, color and specs per project demands.
Easy Operation and Maintenance
User-friendly controls & accessible service points simplify operation and daily upkeep.
Professional Export Support
One-stop export service: selection, quotation, logistics, documents & aftersales.
