The 490W skid steer loader is a highly efficient and versatile machine, combining a compact design with powerful lifting capabilities. It is suitable for confined urban spaces and rugged outdoor environments, enabling efficient operation for professional construction projects.
Description
The 490W Skid Steer Loader is a powerful and versatile solution designed for efficiency across diverse terrains. With an operating weight of 1,050 kg and a rated capacity of 430 kg, it offers a lightweight footprint without compromising on lifting performance. This model is specifically engineered for operators requiring faster cycle times, featuring an impressive max travel speed of 8.5 km/h.
Powered by a reliable 16.8 kW engine (available in ROTO, Koop, or Briggs & Stratton configurations), the machine ensures stable power delivery for demanding material handling. Its optimized dimensions, including a 1,100 mm chassis width and a 320 mm ground clearance, allow it to excel in both confined urban spaces and rugged outdoor environments where obstacles are common.
With a dump height of 2,173 mm and a max working height of 2,715 mm, it provides excellent reach for loading high-sided trucks or stacking materials. The 1,660 mm front turning radius and responsive hydraulic system make it a top-tier choice for professional contractors seeking agility and speed on the job site.
Key Advantages
Enhanced Speed and Mobility
-
8.5 km/h maximum travel speed for rapid movement across large job sites.
-
320 mm high ground clearance for superior performance on uneven or rocky terrain.
-
30° departure angle allows for easy navigation of slopes and ramps.
Superior Lift and Reach
-
2173 mm dump height facilitates easy loading of standard construction vehicles.
-
2715 mm max pin height provides the vertical range needed for specialized lifting tasks.
-
111° bucket rollback angle ensures maximum material retention during transport.
Compact and Versatile Build
-
1100 mm width maintains a compact profile for narrow access areas.
-
1660 mm tight turning radius ensures efficient operation in restricted zones.
-
20L fuel and oil tanks support extended operation hours with reduced maintenance stops.
Parameter
| Category | Item | Unit | Value |
| Performance | Operating Weight | kg | 1050 |
| Rated Operating Capacity | kg | 430 | |
| Tipping Load | kg | 550 | |
| Max. Travel Speed | km/h | 8.5 | |
| Engine | Engine Brand | – | ROTO / Koop / BRIGGS&STRATTON |
| Engine Power | kW / rpm | 16.8 / 3600 | |
| System | System Pressure | MPa | 20 |
| Fuel Tank Capacity | L | 20 | |
| Oil Tank Capacity | L | 20 | |
| Working Dimensions | Max. Working Height | mm | 2715 |
| Max. Pin Height (Bucket Pivot) | mm | 2715 | |
| Dump Height | mm | 2173 | |
| Dump Reach (Distance from machine) | mm | 825 | |
| Dump Angle | ° | 17 | |
| Max. Bucket Rollback Angle | ° | 111 | |
| Max. Bucket Angle (at ground level) | ° | 22 | |
| Overall Dimensions | Overall Height | mm | 2115 |
| Overall Width | mm | 1100 | |
| Bucket Width | mm | 1050 | |
| Overall Length (with bucket) | mm | 2385 | |
| Overall Length (without bucket) | mm | 1885 | |
| Wheel Track | mm | 936 | |
| Max. Ground Clearance | mm | 320 | |
| Max. Departure Angle | ° | 30 | |
| Max. Turning Radius (Front) | mm | 1660 |
Application Scenarios
Stable Performance
High-quality construction ensures reliable operation under all working conditions.
Powerful Digging Force
Strong hydraulic system delivers efficient excavation and high productivity.
Wide Model Range
From mini to heavy excavators, for landscaping, municipal, roadwork, mining, and large projects.
Flexible Attachments
Compatible with buckets, grapples, breakers, and other tools to handle diverse tasks.
Durable & Easy Maintenance
Modular design and robust components reduce downtime and maintenance costs.
Global Standards
Manufactured to meet international safety, quality, and performance standards.
faq
Do you offer customized excavators?
Yes. We offer customization options including configurations, attachments, colors, and selected technical specifications to meet different working conditions.
What quality standards do your excavators meet?
Our excavators are manufactured according to international standards and undergo strict inspection before shipment.
What is your typical delivery time?
Standard models are delivered according to the confirmed production schedule. Delivery time depends on order quantity and customization requirements.
Do you provide after-sales service and technical support?
Yes. We provide technical guidance, spare parts support, and after-sales service to ensure long-term machine performance.
What attachments are compatible with your excavators?
Available attachments include various buckets, hydraulic breakers, grapples, and other tools for different applications.
Which countries do you export to?
Our excavators are exported to many countries, including the USA, Canada, Germany, France, the UK, Italy, Chile, and Ecuador.
How can I choose the right excavator model?
You can share your working conditions, application requirements, and budget, and our team will recommend the most suitable model.
Are your excavators suitable for long working hours?
Yes. Our excavators are built with durable structures and stable hydraulic systems, making them suitable for long and intensive working hours.
