Parameter
|
Item (Name)
|
Specification
|
Item (Name)
|
Specification
|
|---|---|---|---|
|
Model
|
MQR-540
|
Mower Dimensions
|
980 * 920 * 420 MM
|
|
Machine Weight
|
130 KG
|
Package Dimensions
|
1030 * 970 * 560 MM
|
|
Total Weight
|
160 KG
|
Mowing Width
|
540 MM
|
|
Mowing Height
|
30 – 150 MM
|
Operation Mode
|
Remote Control
|
|
Max Remote Distance
|
800 M
|
Start Mode
|
Manual / One-key / Remote Start
|
|
Travel Speed
|
0-6 km/h
|
Max Working Slope
|
45°
|
|
Controller
|
IC Integrated Circuit Controller
|
Power Supply
|
Oil-electric hybrid, Self-generating
|
|
Voltage
|
24V
|
Motor Type
|
350W Brushless Motor
|
|
Fuel Tank Capacity
|
1.4 L
|
Fuel Consumption
|
0.6 L/h
|
|
Blade Drive Method
|
Crankshaft
|
Blade Type
|
Straight double-edged blade
|
|
Number of Blades
|
2 pcs
|
Drive Type
|
Triangular steel track
|
Engine Specifications
|
Item (Name)
|
Specification
|
Item (Name)
|
Specification
|
|---|---|---|---|
|
Brand
|
Loncin / Yamaha / Kohler (Optional)
|
Rated Power
|
9HP / 7.5HP / 9HP (Optional)
|
|
Engine Type
|
4-Stroke
|
Displacement
|
224CC / 190CC / 224CC (Optional)
|
|
Emission Standard
|
EURO5 / EPA / JIS
|
Reliable Performance
Stable performance across all working conditions for efficient, consistent operation.
Durable Construction
Reinforced frame & premium parts extend service life.
Wide Product Selection
Full lineup: construction, landscaping, road compaction & mobile lighting gear for diverse industries.
Flexible Configuration
Customizable models, power, capacity, color and specs per project demands.
Easy Operation and Maintenance
User-friendly controls & accessible service points simplify operation and daily upkeep.
Professional Export Support
One-stop export service: selection, quotation, logistics, documents & aftersales.
faq
What information should I provide when requesting a quotation?
Please provide the required product, application, working conditions, quantity, destination country, preferred configuration and any certification or customization requirements. This information helps us prepare a more accurate recommendation and quotation.
How can I choose the right machine model?
You can send us your application, working environment, required capacity, preferred power type, operating time, quantity and budget. Our team will compare suitable models and recommend an appropriate configuration.
Do you provide customized machinery?
Yes. Depending on the product and order quantity, we can provide selected customization options such as machine color, logo, power system, working capacity, attachments, electrical specifications, packaging and other configurations.
Do you support OEM and ODM orders?
Yes. OEM and ODM services are available for qualified orders. Available customization depends on the product model, technical feasibility and order quantity.
How do you control product quality?
Raw materials, structural components, power systems, electrical parts and machine functions are inspected during production. The completed machine is also checked according to the confirmed order before packaging and shipment.
What certifications are available?
Certification availability depends on the product model and destination market. Selected models may support CE, EPA or other compliance documents. Please contact our team to confirm the exact certification available for your selected machine.
What is your typical delivery time?
Delivery time depends on the product model, order quantity, production schedule and customization requirements. Standard configurations can generally be prepared faster than customized machines. The estimated delivery schedule will be confirmed before the order is placed.
Do you provide operation manuals and technical guidance?
Yes. Available support may include operation manuals, maintenance guidance, product videos, remote technical communication and basic troubleshooting assistance.
